汽车按压锁扣 垃圾桶反弹开关 弹簧卡扣箱 RD-03

1. Storage Temperature: -40°C to 90°C

Operating Temperature: -35°C to +80°C

2. At room temperature:

- Door lock operation press force: 3.5N ± 1.5

- Maximum holding force given to the counterpart in the locked state: >10N

3. Durability Requirements:

At room temperature, with a normal operating force of 3.5N, the product should be able to lock and unlock in one cycle within 3 seconds. The product should undergo over 30,000 cycles without functional failure.

4. The product must comply with ROHS environmental protection requirements

1. 储存温度：—40摄氏度至90摄氏度；

   使用温度：—35摄氏度至+80摄氏度




2. 在室温下，门锁操作需要3.5N±1.5的按压力。

锁止状态，给与对手件的最大负荷力：>10N。

3. 耐久性要求：

（1）在常温下，正常操作力3.5N，产品锁止→解锁，一周期为3秒，连续三万个周期以上功能不会失效。

4. 产品必须符合ROHS环保要求。
